Manufacture Of Tomato Sauces And Ketchups
Nov 29, 2019
Ketchup Mixing Machine is a professional system for mayonnaise and the other oil or water phase emulsified ingredients, according to the production process of mayonnaise and the like...
Product Details
Product Introduction
Ketchup Mixing Machine is a professional system for mayonnaise and the other oil / water phase emulsified ingredients, according to the production process of mayonnaise and the like, the stirring type of ketchup mixing machine is more suitable for mixing products whose viscosity similar to ketchup. Emulsification is the core of the production of ketchup , mayonnaise, custard sauce, and salad dressing. We adopt a production method based in capacity, makes the oil phase to be emulsified into microscopic liquid drops and complexing with the aqueous phase and the emulsifier the first time so that getting a stable emulsion system of oil in water, thus solving problems like too wide oil droplet size distribution, poor stability of the product type, and vulnerable to the risk of oil spills etc., on the principle of on-line three-phase micro-emulsification, The oil / water phase is divided into small units, then met in the emulsifying function area, completed the complexation between emulsifier and oil / water emulsion. This design allows the designer to specify the partition of the functional area in the whole system, and better to adjust and optimize the whole manufacturing process. Such as in emulsion functional areas, JPS series strengthens emulsify which easily cause by the macro emulsification method and mixing stirring modes that interfere with each other. In addition, ketchup mixing machine has the expanding ability of online continuous production.
Technical Parameter
From pilot plant to production systems
Types of plant | JPS5 | JPS50 | JPS100 | JPS300 | JPS500 | JPS650 | JPS800 | JPS1000 | JPS2000 |
Working volume | |||||||||
Max.volume/L | 4 | 35 | 85 | 250 | 400 | 500 | 650 | 850 | 1800 |
Min.volume/L | 1 | 10 | 10 | 20 | 30 | 30 | 30 | 50 | 100 |
Output parameters | |||||||||
Mayonnaise plant capacity, kg/h | 50 | 200 | 500 | 1200 | 1600 | 2500 | 3000 | 4000 | 5500 |
Process parameters | |||||||||
Stirring power/Kw | 0.12 | 1.1 | 2.2 | 2.2 | 4 | 4 | 5.5 | 5.5 | 7.5 |
Emulsifying power/Kw | 4 | 4 | 7.5 | 11 | 18.5 | 22 | 22 | 37 | 45 |
Rotational speed/RPM | 6000 | 4500 | 4500 | 4500 | 4500 | 4500 | 4500 | 4500 | 4500 |
Dimensions /mm | 800* | 1200* 1450* 1800 | 1350* 1500* 1800 | 1700* 4500* 2500 | 2400* 4500* 3200 | 2400* 4500* 3200 | 2700* 5000* 3600 | 2700* 5000* 3800 | 3500* 6000* 4350 |
(**Non-standard equipment parameters are for reference only)
FAQ
Q1. What about your factory?
A: One of our factory is located in Jiangsu and another one is in Fujian province. We have more than 25 workers in our factory, over 6 years experience on food, cosmetic and pharmaceutical machinery making.
Q2. What do we do if we encounter problem about the machine?
A: Showing us the picture or video of the problem. If the problem can be solved by your workers, we will send you solution by video or pictures. If the problem out of your control, our engineer will be sent to your factory (customer will pay the fee during the trip).
