Powder Liquid Mixing Homogenizer

The inline powder liquid mixer is equipped with a specially designed screw rotor, a mixing head, a dispersing head, a liquid inlet and a powder inlet. The working principle is to make use of the high-speed rotation of the stator and rotor to produce the feed, and to introduce the powder into the fast flowing liquid continuously and evenly, and then to disperse and mix the powder through the shear cavity. Because the liquid and powder are not in contact with each other before mixing, only in the moment before mixing, the powder is introduced into the liquid flow as dispersion, so the probability of agglomeration between the powder is less.

Send Inquiry

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

产品介绍

Water soluble fertilizer powder liquid mixing homogenizer

The powder-liquid mixer uses the high-speed rotation of the special rotor and the liquid flow to produce vacuum. With the help of vacuum, the powder is continuously and evenly introduced into the fast flowing liquid. After high-speed shearing, the powder is uniformly dispersed and mixed in the liquid phase. Because the liquid and powder are not in contact with each other before mixing, only in the moment before mixing, the powder is introduced into the liquid flow in the form of dispersion, so it can effectively achieve the purpose of powder / liquid mixing, dispersion and homogenization, and prevent powder agglomeration and secondary agglomeration. The shearing type powder liquid mixer has strong conveying capacity. According to the characteristics of the product, the powder performance can reach 70% concentration.

技术参数

Model	Liquid flux L/H	Powder capacity Kg/h	Power kw	Powder input/ liquid input/ output size DN
PLM-2	500	100	2.2	38/25/25
PLM-4	700	180	4	38/50/40
PLM-5	1500	350	5.5	38/50/50
PLM-11	4500	1000	11	50/50/50
PLM-15	6000	1500	15	50/50/50
PLM-18	7000	2000	18.5	80/65/65
PLM-22	8000	2500	22	80/65/65
PLM-37	10000	4000	37	100/80/80

What can it do?

Thickener compounding: such as Carbomer, xanthan gum, starch, etc

Powder liquid mixed dissolution: such as sugar, milk, citric acid, etc

Additive ingredients: pigment, pigment, vitamin, etc

Dye coating: battery paste, copper clad laminate, silica dispersion, lithium iron phosphate dispersion, kaolin dispersion, etc

Suspension preparation: pesticide, medicine, etc

Daily chemical industry: washing liquid, hand washing liquid, cream, etc

What are its advantages?

-Single equipment can complete mixing, homogenization, emulsification, dispersion, dissolution and other processes.

-The powder material (solid phase) and solvent (liquid phase) can realize on-line humidification, and rarely agglomerate. The instantaneous dispersion / homogenization of powder / liquid / liquid material greatly improves the production efficiency.

-Avoid flying dust and improve production environment.

-Suitable for high viscosity viscous materials.

-Suitable for circular processing / continuous production.

-A variety of process structures can be selected, which can be widely used in various liquid batching processes.

-Non standard customization according to material characteristics, more applicable, more convenient and more energy-saving.

-Continuous dispersion process has the advantages of high mixing efficiency, short time and low energy consumption.

-Fully closed dispersion chamber can avoid the influence of air introduction on dispersion effect. The equipment can realize on-line cleaning, and the cleaning operation is convenient and efficient.

-The fully enclosed distributed system can work under pressure, and the continuous process can realize mass production. The equipment covers a small area and has low maintenance cost.

-The energy input of fine dispersion is controllable, and the particle size distribution is narrow after mixing, and the product quality is more stable.
