Mayonnasie Making Homogenizer
video
Mayonnasie Making Homogenizer

Mayonnasie Making Homogenizer

Food Vacuum Emulsifying Mixer introduces foreign advanced technology and is designed according to the manufacturing process of mayonnaise, salad dressing and other products. The unit is composed of pretreatment water tank, vacuum emulsion mixing main pot, vacuum pump, hydraulic system, discharge system, electrical control system, PLC touch screen, working platform, etc. The unit has the characteristics of simple operation, stable performance, good homogenization performance, high production efficiency, convenient cleaning, reasonable structure, small floor area and high degree of automation.

  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

The material can be discharged after the emulsification is complete and meets the process requirements:

Before discharging, rotate "emulsification" to the left or directly press the emergency stop button of "emulsification mixing frequency converter" to stop the operation of emulsification head, but the slow mixing device cannot stop:

Rotate the "bottom valve discharge" button to the right, open the bottom discharge valve of the emulsifying machine, and the materials in the vacuum emulsifying machine can be transported to the storage tank through the transport pump:

After the discharging operation is completed, the feeding can be started. If it is not necessary to feed, the equipment can be cleaned.

The development of vacuum emulsifying machine is accelerating in modern society. Improving the production quality and efficiency is the basic element of vacuum emulsifying machine. Yuxiang developed and manufactured vacuum emulsifying machine, its material, structure and layout; Design and manufacture in strict accordance with the manufacturing requirements of food and drug machinery and equipment. Ensure that every product provided has first-class quality standards and excellent performance.

vacuum homogenizer mixer




Specification

MODEL
Batch capacity /H
Capacity(L/H)
Power /KW
Size(mm)
Remarks
JPS-5
2-4
15-25
5
800*900*900
Laboratory Machine
JPS-10
2-8
15-50
6.5
850*900*900
Small test Machine
JPS-50
10-40
40-150
15.3
1200*1250*1850
Pilot Machine
JPS-80
20-50
80-200
15.3
1200*1250*1850
Pilot Machine
JPS-150
30-120
120-480
27
1500*1750*3550
Production System
JPS-250
40-200
160-750
31.2
1500*1750*3550
Production System
JPS-650
40-500
200-2000
41
2000*2400*4500
Production System
JPS-1300
60-1000
300-3000
52
2300*2400*4900
Production System

Product Description

mayonnaise making machine

homogenizer mixer


Exhibitions

6

homogenizer mixer factory
