Homogeneous Mixing Machine

Homogeneous Mixing Machine

Homogeneous Mixing machine Vacuum Mixer Homogenizer means when the materials are under the vacuum condition, it makes use of the high shear emulsifier to distribute one or several to another continuous phase rapidly and evenly. The materials will be processed in the narrow space between stator and rotor by strong energy of motion produced by the machine effect.

  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

Homogeneous Mixing machine

Features of liquid soap mixing equipment

1. The blending system adopts single-direction or double-direction wall scraping blending and frequency converter for speed adjustment to satisfy production of high quality products according to customer requirements.
2. According to technological requirement, the tank can heat and cool materials. The heating way including steam heating and electric heating for choice.
3. The jacketed pot is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements.
4. Various forms of blending vanes are suitable for production of different types of products.

5. Easy to discharge, bottom direct discharge or by transfer pump.


    vacuum homogenizer mixer

    JPS sauce making machine

    vacuum homogenizing mixer3

    mayonnaise making machine

    Specification

    MODEL
    Batch capacity /H
    Capacity(L/H)
    Power /KW
    Size(mm)
    Remarks
    JPS-5
    2-4
    15-25
    5
    800*900*900
    Laboratory Machine
    JPS-10
    2-8
    15-50
    6.5
    850*900*900
    Small test Machine
    JPS-50
    10-40
    40-150
    15.3
    1200*1250*1850
    Pilot Machine
    JPS-80
    20-50
    80-200
    15.3
    1200*1250*1850
    Pilot Machine
    JPS-150
    30-120
    120-480
    27
    1500*1750*3550
    Production System
    JPS-250
    40-200
    160-750
    31.2
    1500*1750*3550
    Production System
    JPS-650
    40-500
    200-2000
    41
    2000*2400*4500
    Production System
    JPS-1300
    60-1000
    300-3000
    52
    2300*2400*4900
    Production System

    Product Description

    mayonnaise making machine

    homogenizer mixer


    homogenizer mixer

    Certifications


    Exhibitions

    6
