500L Vacuum Emulsifying Mixer
1. Complex scraping board blending oar is suitable to every kind of complicated recipe and achieve optimizing effect;China Factory Wholesale Cream Vacuum Emulsifier 2. Polytetrafluroethylene scraping board cater to body of blending groove and scrape out viscosity material on boiler wall;China Factory Wholesale Cream Vacuum Emulsifier 3. Cosmetic cream vacuum mixer homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. During few production, it can exert homogenizing effect fully; 4. Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high-capability cut, rubbing, centrifugal to make sure exquisite and slick cream; boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation. 5. Customer can choose frequency conversion timing homogenizer and highest rotate speed is 4500 r/min.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
The 500L Vacuum Emulsifying Mixer is a non-standard customized equipment, which is reasonably configured according to the customer's process, and is applicable to the products that need to be emulsified and stirred in the vacuum state. It can be used for emulsifying and stirring high viscosity products with low-speed wall scraping and stirring. It can be equipped with high shear emulsifying machine, suitable for dispersion, emulsification, homogenization, mixing and other processes. The vacuum emulsifying machine is mainly composed of water phase boiler, oil phase boiler, emulsifying mixing main boiler, vacuum system, lifting system (optional), electrical control system (PLC can be selected), operation platform, etc.
working principle:
After the materials are heated, stirred and mixed in the water and oil pots, they are sucked into the emulsifying pot by the vacuum pump. Through the two-way cutting, compression and folding of the wall scraping mixing frame and the central mixing paddle in the emulsifying pot, their mixing flows downward to the homogenizer below the pot. The high tangent speed and the strong kinetic energy brought by the high-frequency mechanical effect caused by the high-speed rotation of the homogenizer rotor make the materials stable The narrow clearance of the rotor is subject to the comprehensive effects of strong mechanical and hydraulic shear, centrifugal extrusion, liquid layer friction, impact tearing and turbulence. The micronization, emulsification, mixing, blending and dispersion of materials are completed in a short time. The immiscible solid phase, liquid phase and gas phase are dispersed and emulsified in an instant under the action of the corresponding mature process, and finally stable high-quality products are obtained.
The emulsifying pot can be vacuumized to remove the bubbles generated during the mixing process.
The contact part between the whole machine and the materials is made of high-quality SUS316L materials, the inner surface is polished, and the vacuum mixing device is clean, which meets the GMP sanitary standard.
Scope of application:
Food: reduced milk, salad dressing, mayonnaise, ice cream, cheese, milk beverage yogurt, fruit juice
Medicine: cytoplasmization, drug synthesis, vaccine, fat emulsion, suspension, ointment, preparation
Cosmetics: shampoo, cream, toothpaste, eye black, shower gel, carbo
Chemical industry: synthetic rubber, resin, asphalt, silicone oil, flocculant, white carbon black, photosensitive agent, softener, dye, paste, coating, bentonite, ink, water-based paint, titanium dioxide.
